Function and Use

The paper tube pressure tester of Guangzhou Shounuo Scientific Instrument Co., Ltd. is suitable for paper tubes with an outer diameter of 200mm. It is also called paper tube pressure tester and paper tube compression tester. It is a basic instrument for testing the compressive performance of paper tubes. It adopts high-precision sensors and high-speed processing chip design to ensure sampling accuracy.

Compliant with standards

BB/T 0032, ISO 11093-9, GB/T 22906.9, GB/T 27591-2011

Instrument Features

1. After the test is completed, it has an automatic return function, automatically determines the crushing force and automatically saves the test data;

2. The speed is adjustable, the full Chinese LCD display operation interface, and a variety of units are available;

3. Equipped with a micro printer, the test results can be directly printed.

Technical parameters

Capacity selection: 1 T (optional 500 kg,)

Outer diameter of paper tube: 200 mm Test space: 200*200

Test speed: 10~150 mm/min

Force resolution: 1/200000

Display resolution: 1 N

Accuracy level: Level 1

Displacement unit: mm, cm, m

Force unit: kgf, gf, N, kN, lbf

Stress unit: MPa, kPa, kgf/cm2, lbf/in2

Software function: Chinese and English language interchange

Safety device: overload protection, limit element protection device

Machine power: AC variable frequency motor drive controller

Mechanical system: high-precision ball screw

Power supply: AC220V/50HZ~60HZ 4A

Control mode: microcomputer control (optional computer operating system)

Display mode: electronic LCD display (optional computer display)

Stop mode: overload shutdown, automatic shutdown due to specimen damage, automatic shutdown due to upper and lower limit settings

Machine weight: about 120 kg

Instrument configuration

Host, other accessories
